Jacobsen Turfcat T628D User Manual

3 DECALS
9
Familiarize yourself with the following decals. They are critical to the safe operation of the
machine. REPLACE DAMAGED DECALS IMMEDIATELY.
1
2
3
4
5
6 8
3
7
9
FLUID QUANTITY TYPE
Service Items
Hours of
Operation
DAILY
SERVICE NOTES:
80 100 400 600
HYDRAULIC OIL
RADIATOR COOLANT
0.88 gallons (3.3 liters)
6.8 gallons (25.3 liters)
1.70 gallons (6.4 liters)
10W30 SF-CD
(Trailing numbers show location on diagram for service items)
Check Interlock System
2-WHEEL DRIVE ONLY
2-WHEEL DRIVE ONLY
Check Engine Oil (1) Check Hydraulic Oil Level (5) Check Coolant Level (7)
Check Water Separater (6) Check Tire Pressure Check/Clean Engine Compartment, Radiator & Screen
No service is a one-time job. These hours
are intervals between EACH service.
SERVICE MORE OFTEN
UNDER DIRTY CONDITIONS.
• Change engine oil, hydraulic oil and both oil filters FIRST 50 hours of operation. • Refer to engine manual for engine maintenance.
Clean Air Cleaner Particle Collector Verify Cutter Deck Belt Tension Lubricate Grease Fittings Replace Ait Cleaner Element (2)
Check/Top-up Battery Check Fastner Tightness Check Fan Belt Tension Change Engine Oil & Filter (3) Change Hydraulic Oil & Filter (4) Service Engine Per Engine Manual Change Fuel Filters (8) Check Rear Wheel Toe-In Drain & Clean Fuel Tank Drain & Flush Cooling System (9)
10W30 SF-CD
50% ANTI-FREEZE
X X X X X X X
X X
Every week
Every 400 hrs
(
sooner for dirty operating conditions)
X X X X
X X X X
X X
2722063
