Jacobsen Turfcat T628D User Manual

DECALS 3
8
LOWER
DECK
LIFT
RAISE
2000728
HYDRAULIC FLUID
- USE 10W30 OIL
- MAINTAIN FLUID LEVEL AT
MIDDLE OF SIGHT TUBE.
2000729
PARKING BRAKE
- DEPRESS PEDAL(S)
FULLY TO SET LATCH
- SEE OPERATOR’S
MANUAL
2000727
CASTER
MOUNT
Caster Mount Spacers Hanger Hole Height of Cut
Actual height may vary due to tire pressure and condition.
See Operator's Manual for more information.
00555
Height of Cut Chart
LOW
LOW
LOW
LOW
LOW
LOW
LOW
LOW
HIGH
HIGH
HIGH
HIGH
HIGH
HIGH
HIGH
HIGH
0
1/4"(1)
1/4"(2)
1/2"(1); 1/4"(1)
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
1"
1-1/4"
1-1/2"
1-3/4"
2"
2-1/4"
2-1/2"
2-3/4"
3"
3-1/4"
3-1/2"
3-3/4"
4"
4-1/4"
4-1/2"
4-3/4"
HANGER
DECK
1/2"(2); 1/4"(1)
1/2"(3); 1/4"(1)
1/2"(2)
1/2"(3)
0
1/4"(1)
1/4"(2)
1/2"(1); 1/4"(1)
1/2"(2)
1/2"(2); 1/4"(1)
1/2"(3)
1/2"(3); 1/4"(1)
1
2
4
5
6
8
3
7
SPACERS
HIGH
LOW
Operator’s
Manual
Inflate tires
to 14 psi
(1.0 kg/cm
2
)
2000673
Reverse Forward
00225
