Brassware
QBASE - DREAM
Lift the mixer lever (M) and turn it to the right or left until reaching a pleasant tempera-
ture.
D
M
QOpen the tap (R) and turn the mixer knob (M) so that the reference mark coincides with
the desired temperature (to select temperatures above 38 °C press the release button (P).
P
M
D
R
QHOME SPA
Open the tap (R) and turn the mixer knob (M) so that the reference mark coincides with
the desired temperature (to select temperatures above 38 °C press the release button (P).
R
P
M
38°C
3
8
50
D
QAll models
To test the water temperature, turn the diverter dial (D) to the position "single jet shower",
grasp the hand held shower head and turn on the water. Adjust it if necessary by turning
the tap or mixer knob.
Once the desired water temperature is obtained, turn the dial to the position that identi-
es the function you want to use.
single-control
thermostatic
thermostatic
