Jacuzzi ERIKA 48 - Door Panel Installation

14
1-2. Install the 2 door rollers (H) on the door glass panel (J). Use a ratchet to strongly tighten the bolts. Insert
the clip (L) at the bottom roller.
3-4. Gentlyhangthedoorpanelbyits2rollers(H)onthexedpanel(C)andtherollerguidetrack(O).
5. Slide the auxiliary roller (E) into the door panel (J).
DOOR PANEL INSTALLATION
H
J
L
H
J
3
J
C
4
J
O
J
E
5
H
1 2
