Control Panel
2
I
B
A
E
C
D
F
H
1
G
J
Control panel for models with 2 pumps.
A. CLEARRAY™ ( ) Button: Manually activates the CLEAR-
RAY™ system for a one-hour period.
B. ICLEARRAY™ Indicator Light: Lit when the CLEARRAY™ sys-
tem is on.
C. Light On/O ( ) Button Options: Turns waterfall light,
footwell light, lighted cup holders and backlit pillows on in uni-
son. Press once for high intensity; press a second time for medi-
um intensity; press a third time for low intensity; press a fourth
time to turn o. The displayed color is changed using the light
mode button (D) below.
D. Light (
) Button : Selects one of 4 light color modes for
waterfall, footwell, cup holders, and pillow lights.
E. Cooler ( ) Button: Decreases water temperature set point.
Also used to navigate through the programming menus.
F. Warmer ( ) Button: Increases water temperature set point.
Also used to navigate through the programming menus.
G. Jets 1 (
1
) Button: Turns jets pump #1 on and o.
H. Jets 2 (
2
) Button(J-335/J-345/J-355/J-365/J-375/J-385):
Turns jets pump #2 on and o.
I. Menu ( ) Button: Allows access to the programming men-
us.
J. LCD Display: Can display current water temperature (default
display), water temperature set point, selected menu functions,
and error messages.
Operation Details
Temperature Adjustment: 65 to 104°F (18 to 40°C). Factory de-
fault setting is 100°F (38°C).
CLEARRAY™ Operation: System runs for 1 hour (when manually
activated), then automatically shuts o.
Light Operation: All LED lights run for 2 hours, then automatically
shut o.
Jets 1/Jets 2 Button Operation: Jets run for 20 minutes when activat-
ed, then turn o automatically to conserve energy. Simply press ei-
ther jets button to continue operation for an additional 20 minutes.
