Operating instructions
The spa control system has automatic functions that operate upon
start-up and normal operation to protect the system.
Upon power up, the display shows the following information:
1. Control panel displays all lit indicators, permitting visual in-
spection of all display segments and indicator lights for proper
operation.
2. Control panel displays the controller and control panel soft-
ware versions.
3. Control panel scrolls the message, “WELCOME TO JACUZZI.”
4. Control panel scrolls the message, “PLEASE REGISTER YOUR
SPA AT WWW_JACUZZI_COM.”
Note: It is common for the heater to turn on after the spa is rst
lled because tap water is often very cold. If water temperature,
at this time, is less than the factory default temperature setting
of 38°C (100°F) the heater will turn on and run until the water
temperature rises to the factory setting, then turn o.
Register Your New Spa
To register you will need to have the spa serial number, then you
will need to register online. If this option is skipped, you will be
able to activate components, but, after 10 minutes, the screen
will revert back to the registration message. This process will con-
tinue until the spa is registered and the passcode is entered.
Note: The spa will still protect itself if an error is detected.
serial nameplate
To register your spa you need to have your spa serial number. The
best time to retrieve the serial number is when the spa is being con-
nected. You must register your spa via the internet at www.Jacuzzi.
com.
Follow these steps to register your spa.
1. Using your home computer or other device, connect to the
internet.
2. Go to www.Jacuzzi.com website to register your spa.
3. Click Outdoor Hot Tubs
4. Click For Owners
5. Click Warranty and Manuals
6. Click Warranty Registration
7. Enter your serial number.
8. Once registered you will be given a passcode that will need to
be entered into the control panel.
Keep a record of your serial number and passcode for any future
reference. Write that information below.
Serial Number: _ _ _ _ _ _ _ _ _
Passcode: _ _ _ _ _ _ _ _ _
Completing Your Registration
Once the spa is registered online, you will continue the process
at the spa control panel. You will need to enter the serial number
and passcode given when you registered online. Follow the steps
below.
Note: The control panel does not have a back button. If an incor-
rect number is entered you must complete the entire registra-
tion steps. At that point, the system will return an “INCORRECT
PASSCODE” message.
A. Entering the Serial Number and Passcode
1. Press (
) until you get to the “S\N” Menu. The display will
scroll “SET SERIAL NUMBER.”
Note: Once a valid serial number and passcode have been en-
tered, this screen will not appear again.
2. Press (
1
) to prepare the system.
3. Enter the serial number. Using the or buttons you can
cycle through the numbers 0 to 9.
4. Once you reach a desired number release the button. Press (
1
) after selecting each of the numbers and allow the cursor to
move to the next selection. After the last number is saved, pro-
ceed to enter the passcode.
6. Using or you can cycle through the numbers 0 to 9.
7. Once you reach a desired number release the button. Press (
1
) after selecting each of the numbers and allow the cursor to
move to the next selection.
8. If the passcode is correct, the display will scroll “PASSCODE
ACCEPTED.” If there was error, the display will scroll “INCORRECT
PASSCODE.” You will need to re-enter the passcode.
Setting water temperature
Press (or press and hold) either ( or ) to adjust the current
temperature setting. Once the desired temperature is reached,
do not press any buttons on the control panel for about 3 sec-
onds. The new temperature setting will saved. When the spa is
heating the heat icon ( ) will be displayed.
Activate Jet Pumps
1
2
The JETS 1 (
1
) button activates jets pump 1. The rst press
turns jets pump 1 on; the second press turns jets pump 1 o. The
JETS 2 (
2
) button activates jets pump 2 (if equipped). The rst
press turns jets pump 2 on; the second press turns jets pump
2 o. When manually activated, either pump will automatically
turn o after 20 minutes.
Light On/O Button
Pressing this button activates the waterfall light, footwell light,
lighted cup holders, and backlit pillows lights in unison as fol-
lows: high - medium - low - o.
Note: Lights automatically turn o after 2 hours

Jacuzzi J-385 Specifications

General

Seating Capacity	6-7 Adults
Pumps	2
Circulation Pump	Yes
Primary Pump	2.5 HP
Secondary Pump	2.5 HP continuous duty, 4.8 HP breakdown torque
Electrical Requirements	240V
