Jacuzzi J-385 User Manual

14
J-300
Export Models (50 Hz) Service
Single Breaker
Service 1
(including Heater)*
Single Breaker
Service 1 (including
Heater)**
Voltage: 230 VAC 230 VAC
Max. Current Draw:
1-Pump System 15A 22A
2-Pump System 17A 29A
Wattage:
1-Pump System: 3.5 kW 5.1 kW
2-Pump System: 3.9 kW 6.7 kW
Frequency: 50 Hz 50 Hz
Number of Wires: 3 3
Single Breaker is the factory default.
* For this service, the heater will not operate while either jets pump is
running. The service 1 breaker will include connection for all components.
** For this service, the heater will operate while two jets pump are running.
The service 1 breaker will include connection for all components.
Export Models (50 Hz) Service
Dual Breaker
Service 1/
Service 2***
Three Phase Service
Service 1/
Service 2/Service 3***
Voltage: 230 VAC 230 VAC
Max. Current Draw:
1-Pump System 12A/10A N/A
2-Pump System 12A/17A 12A/10A/7A
Wattage:
1-Pump System: 2.8kW/2.3kW N/A
2-Pump System: 2.8kW/3.9kW 2.8kW/2.3kW/1.6kW
Frequency: 50 Hz 50 Hz
Number of Wires: 5 5
Single Breaker is the factory default.
*** For this service, the heater will operate while two jets pump are running.
The service 1 breaker will include connections for the heater and
transformer. The service 2 breaker is for all other components.
****
In this conguration, the heater will operate while all jets pumps are
running. The service 1 breaker will include connections for the heater
and transformer. Service 2 breaker is for pump 1 and other components.
Service 3 breaker is for pump 2.

Jacuzzi J-385 Specifications

General

Seating Capacity	6-7 Adults
Pumps	2
Circulation Pump	Yes
Primary Pump	2.5 HP
Secondary Pump	2.5 HP continuous duty, 4.8 HP breakdown torque
Electrical Requirements	240V
