J-300
6.0 Power Requirements
Jacuzzi spas are designed to provide optimum performance
and exibility of use when connected to the maximum electrical
service listed below. Minor circuit board modications can be
performed to allow your new spa to accept an electrical service other
than the factory operation setting.
Note: Refer to pages 56-60 for circuit board conguration details or
contact your authorized Jacuzzi dealer.
North American J-335, J-345, J-355, J-365, J-375 and J-385 Models
(60 Hz)
240V/40A* 240V/50A** 240V/60A***
Circuit Breaker (2-Pole): 40A 50A 60A
Number of Wires: 3 3 3
Frequency: 60 Hz 60 Hz 60 Hz
Current Draw: 26A 37A 48A
*
In 40A conguration, the heater will not operate while either jets
pump is running.
**
In 50A conguration, the heater will not operate while both jets
pumps are running. This is the factory setting.
***
In 60A conguration the heater will operate while both jets pumps
are running.
North American J-315 and J-325 Convertible Models (60 Hz)
120V/15A* 240V/30A* 240V/40A**
Circuit Breaker: 15A, 1-Pole 30A, 2-Pole 40A
,
2-Pole
Number of Wires: 3 (15A GFCI
Cord US
Only*)
4 (Hard Wire
Only)
4 (Hard Wire
Only)
Frequency: 60 Hz 60 Hz 60 Hz
Current Draw: 12A 20A 31A
*
In 15A/30A conguration, the heater will not operate while the jets
pump is running. The factory setting is 120V/15A.
**
In 40A conguration, the heater will operate while the jets pump is
running.
**CAUTION: (For a 4-wire 240 VAC Heater Operation): Make
certain wires are connected exactly as shown in Figure D (page 18)
before applying power. Failure to do so will result in damage to the
circuit board and/or related components and void the manufacturer's
warranty.

Jacuzzi J-385 Specifications

General

Seating Capacity	6-7 Adults
Pumps	2
Circulation Pump	Yes
Primary Pump	2.5 HP
Secondary Pump	2.5 HP continuous duty, 4.8 HP breakdown torque
Electrical Requirements	240V
