9.0 Control Functions
9.1 Control Panel
A. CLEARRAY ( )Button:
Manually activates the
CLEARRAY system for a one-
hour period.
B. CLEARRAY Indicator: Lit when the CLEARRAY is on.
C. Light On/Off ( ) Button Options: Turns waterfall light, footwell
light, lighted cup holders and backlit pillows on in unison. Press
once for high intensity; press a second time for medium intensity;
press a third time for low intensity; press a fourth time to turn off. The
displayed color is changed using the light mode button (D) below.
D. Light Mode ( ) Button: Selects one of 4 light color modes for
waterfall, footwell, cup holders, and pillow lights. See page 29 for
additional information.
E. Cooler ( ) Button: Decreases water temperature set point. Also
used to navigate through the programming menus.
F. Warmer ( ) Button: Increases water temperature set point. Also
used to navigate through the programming menus.
G. Jets 1 (
1
) Button: Turns jets pump #1 on and off.
H. Jets 2 (
2
) Button (J-335 to J-385): Turns jets pump #2 on and
off.
I. Menu ( ) Button: Allows access to the programming menus.
J. LCD Display: Can display current water temperature (default
display), water temperature set point, selected menu functions, and
error messages.
Operation Details
• Temperature Adjustment: 65 to 104°F (18 to 40°C). Factory default
setting is 100°F (38°C).
• CLEARRAY Operation: System runs for 1 hour (when manually
activated), then automatically shuts off.
• Light Operation: All LED lights run for 2 hours, then automatically
shut off.
• Jets 1/Jets 2 Button Operation: Jets run for 20 minutes when
activated, then turn off automatically to conserve energy. Simply
press either jets button to continue operation for an additional 20
minutes.
2
I
B
A
2-Pump Control Panel Shown
E
C
D
F
H
1
G
J
