Jacuzzi J-385 User Manual

59
J-300
16.4 Export J-335, J-345, J-355, J-365, J-375 and J-385 Models
(50 Hz)
This wiring diagram is used for all Export 230 VAC 50 Hz spa models.
GRN
L1 BRN N1 BLU
230VAC, 50HZ
SINGLE SERVICE 29A
DUAL SERVICE 12A/17A
THREE SERVICE 12A/10A/7A
CLEARRAY
STEREO POWER
SUPPLY (OPTIONAL)
PUMP 1
LIGHTING
EXPANSION
A B C D
CIRC PUMP
OZONE
P1 2SPD
P2 1SPD
UV
A/V
WATER
SENSOR
WI-FI
(OPTIONAL)
CONTROL
PANEL
PUMP 2
CIRC PUMP
STEP LIGHT
(OPTIONAL)
THERMAL
CUTOFF
FLOW
SENSOR
5AT~250V
2.7KW HEATER
See Section 17.0
for Dip Switch
Settings
30A (PMP 1)
30A (PMP 2)
J33
J36 J53
J41
J46
J47
J51
J59
J38
J44
J49
J22
J23
J24
J9
J14
J18
J17
J50
F4
J27
J34J29
F6
J56
J57
S1
ZONE 1
ZONE 2
F2
J35
J37
4A
5A
1 2 3 4 5 6 7 8 9 10
S1
1 2 3 4 5 6 7 8 9 10
ON
DANGER
Turn power off before servicing. This task should only be performed by a quali
-
fied technician.
!
RISK OF SHOCK OR ELECTROCUTION!

Jacuzzi J-385 Specifications

General

Seating Capacity	6-7 Adults
Pumps	2
Circulation Pump	Yes
Primary Pump	2.5 HP
Secondary Pump	2.5 HP continuous duty, 4.8 HP breakdown torque
Electrical Requirements	240V
