Jacuzzi J-DREAM - Page 35

Remove screws (3 Places)
Remove 2 bolts (2 places)
Panel #1
Service Access (continued)
Remove 3 screws along the door frame post. Then remove 4 hex head bolts along the seat wall. Swing seat wall with
Panel 1 toward back wall. To reassemble, reverse these procedures.
33
