8
2. Attach the water inlet and fill spout to the
tower wall. (See Illustration 2 and 2a.)
ILLUSTRATION 2a
FILL SPOUT
NUT
QTY.-1
W2
LOCKNUT
1/2"-14NPT
FIBER WASHER
1.24 DIA
WASHER
QTY.-1
W1
WATER INLET
ILLUSTRATION 2
NIPPLE
QTY.-1
P5
NUT
CAULK
WASHER
WATER
INLET
TOWER
WALL
W2
W1
P6
CAULK
P7
FILL SPOUT
TOWER
WALL
COMPRESSION
RING
NIPPLE
WASHER
NUT
P5
P8
RUBBER
WASHER
1.75 DIA
WASHER
QTY.-1
P7
LOCKNUT
1/2"-14NPT
LOCKNUT
QTY.-1
P6
COMPRESSION
RING
QTY.-1
P8
