9
3. Attach the wallbar assembly to the tower wall.
(See Illustration 3.)
ILLUSTRATION 3
FLATHEAD
SCREW
#10-24 x 2 1/2"
STAINLESS
STEEL
EXTERNAL TOOTH
WASHER
1/8" BEAD OF CAULK
WALLBAR STAND-OFF
WB4
CAP
SIDE VIEW
OF WALLBAR
WALLBAR
SHOWER HEAD
BRACKET
SOAPDISH
SHOWER
WALL
KEP
NUT
FLAT
WASHER
SCREW
WB3
WB2
WB1
EXTERNAL TOOTH
LOCK-WASHER #10
STAINLESS STEEL
HEX LOCKNUT
#10-24
FLAT WASHER
#10, TYPE B
SCREW
#10-24x4"
S.S.
PARTS NOT NEEDED
NUT
QTY.-2
2
TOGGLE NUT
10-24
SCREW
QTY.-2
1
WASHER
QTY.-2
WASHER
QTY.-2
NUT
QTY.-2
SCREW
QTY.-2
WALL BAR
WB1
WB2
WB3
WB4
