14
Upper Bar Mounts
3
7
5
6
2
1
4
Description Part No.
1 Upper Bar Clamp (4x6) (UBC-2) JM0028447
2 1/2”-13 Gr2 Z Centerlock Hex Nut JM0001511
3 3/4” x 8” Z L Pin (Header Wagon, c450) JM0029738
4 HT974 Scissor Arm (Stalk Roller Option) JM0054841
5 3/16” x 2-1/2” Hair Clip Pin (316HP) JM0001657
6 HT974 Upper Bar Mount/Slide Mount with Tilt JM0062925
7 Upper Bar Support Arm (UBSA-3) JM0003077
8 Upper Bar Slide Mount (UBSM-3) JM0015133
9 Upper Bar Channel Mount 3/4” (UBCM-3) JM0029588
8
9
Stalk Roller Scissor Arm and Upper Bar Mount Standard Scissor Arm and Upper Bar Mount
