18
Light Bar Assembly
1
2
3
5
6
9
8
7
4
14
13
11
15
10
12
Description Part No.
1 Telescoping Arm for Header Transport Light Kit (TA-1) JM0001375
2 1/2”-13 x 4” Gr5 Z Bent L Bolt JM0021419
3 1/2”-13 x 2” Gr8 Z Hex Bolt JM0001620
4 Header Transport Light Mounting Bracket (LMB-1) JM0001374
5 Neoprene Vibration Damping Mount with 5/8” Diameter Hole JM0001869
6 Header Transport Light Mount Extension Bracket (EB-1) JM0001393
7 1/2”-13 x 7” Gr8 YZ Hex Bolt JM0001622
8 Header Transport Light Bar Angle Iron Support (AIS-2) JM0001440
9 1/2”-13 Gr2 Z Centerlock Hex Nut JM0001511
10 Slow Moving Vehicle Sign Bracket JM0001645
11 Slow Moving Vehicle Sign JM0001616
12 1/4” x 1-1/2” Self Tapping Screw JM0001571
13 1/4”-20 Gr2 Z Centerlock Hex Nut JM0001505
14 1/4” ID, 3/4” OD Z Flat Washer JM0003090
15 1/4”-20 x 3/4” Gr5 Z Hex Bolt JM0001507
