JRT Series Heat Pumps

Installation and Operation Manual

9.3 Jandy JRT Heat Pumps Exploded View

DETAIL C

Scale 1 : 8

*See Figure 16

for detail

*Lockbox

not shown

Figure 15. Jandy JRT Heat Pumps Exploded View (JRT2000R Shown)
