Page 10
ENGLISH
Jandy
®
JRT Series Heat Pumps
|
Installation and Operation Manual
Figure 6. Two (2) Heat Pump Plumbing Layout
Manual Bypass Valve
2” PVC
3” PVC
Optional
Isolation Valves
From Filter
To Pool
Figure 7. Four (4) Heat Pump Plumbing Layout
Manual Bypass Valve
Optional
Isolation Valves
From Filter
To Pool
2” PVC
3” PVC
