Jandy JRT3000R - Head Loss Curves

Page 11
ENGLISH
Jandy
®
JRT Series Heat Pumps
|
Installation and Operation Manual
3.5 Head Loss Curves
0
2
4
6
8
10
12
14
20 25 30 35 40 45 50 55 60 65
JRT2000R JRT2500R and JRT3000R
Design Head Loss (PSI)
Flow Rate, Gallons Per Minute (GPM)
Jandy JRT Heat Pump
Head Loss Curves
