Page 13
NOTE When the light is turned OFF for more than
seven (7) seconds, it will remain in the color set
that is currently active. When the light is turned
back ON, the light will be on the same color set.
7.2 To Reset to the Beginning of the
Color Sequence
Turn the light OFF, wait four (4) to six (6) seconds, then
turn ON, the light will return to the beginning of the
color cycle (Alpine White).
NOTE If an AquaLink
®
RS control system is being
used the color set can be selected using the
controller.
NOTE
To synchronize colors on multiple Jandy
WaterColors light systems and Jandy Laminar
Jets with LED Lights wired to separate
switches, preform the above actions on all of the
switches simultaneously. All Jandy WaterColors
lights and Jandy laminar jet with LED lights will
synchronize automatically if activated by the
same switch. No other accessories are required.
Section 8. Light Intensity Set Up
8.1 Light Intensity Adjustment Set
NOTE The LED light intensity can be adjusted to your
preference. Increased water stream fl ow will
cause a greater disturbance of the laminar jet
stream and create a more intense light.
1. Use the light intensity adjustment screw attached
to the scratcher to adjust the light intensity as
shown in Figure 12.
2. To increase the light intensity, turn the screw
counter-clockwise to increase the water stream
coming out of the scratcher. This water stream
disturbs the surface of the laminar jet flow causing
an increase in the light intensity.
NOTE Laminar jets are sensitive to wind, earth
movement and equipment vibration. Secure
the laminar jet and deck canister to minimize
vibration. Periodic stream distortion caused
by pump vibrations and motor electrical
fl uctuations is normal and not indicative of a
nozzle defect. Also, occasionally a nozzle will
“burp” due to pumped air collecting in the nozzle
body. This is normal and will occur until all air
is purged from the piping system. Trapped air
can also cause slight distortion in water action.
It is imperative that all air is removed to ensure
proper water feature operation.
Figure 12. Scratcher Assembly and Light Intensity
Adjustment Screw
Scratcher
Light Intensity
Adjustment Screw
Screwdriver
