Jandy
®
Pro Series, WaterColors LED Lights
|
Installation Manual
 





Thisunderwaterlightmustbeinstalledbyalicensed
orcertifiedelectricianoraqualifiedpoolserviceman
inaccordancewiththeNationalElectricalCodeand
allapplicablelocalcodesandordinances.Improper
installationwillcreateanelectricalhazard,whichcould
resultindeathorseriousinjurytopoolorspausers,
installersorothersduetoelectricalshock,andmay
alsocausedamagetoproperty.

Alwaysdisconnectthepowertothecolorlightatthe
circuitbreakerbeforeinstallingorservicingthelight.
Failuretodosocouldresultindeathorseriousinjury
toserviceman,poolorspausersorothersdueto
electricalshock.
 

 Theelectricianmustcompletepreparatorysteps
beforelightfixtureisinstalled.SeeFigure1.
Ensure that the pool meets the requirements of the
current National Electrical Code and all local codes
and ordinances. A licensed or certied electrician must
install the electrical system to meet or exceed those
requirements before the underwater light is installed.
Some of the requirements of the National Electrical
Code, which the pool electrical systems must meet, are as
follows:
1. The lighting circuit must have a Ground Fault
Circuit Interrupter (GFCI) for 120 volt models,
and must have an appropriately rated circuit
breaker.
2. The junction box (or, for 12 volt models, the low
voltage transformer) must be located at least eight
(8) inches above water level, at least four (4)
inches above ground level, and at least four (4)
feet from the edge of the pool. See Figure 1.
3. The light xture and all metal items within ve
(5) feet of the pool must be properly electrically
bonded to a reliable point of grounding.
4. The wet niche must be properly installed so that
the top edge of the underwater light’s lens is at
least 18 inches below the surface of the water in
the pool. See Figure 1.
5. The wet niche must be properly electrically
bonded and grounded via the No. 8 AWG ground
connector located at the rear of the niche. See
Figure 1.
 Tobecertainthatthepool’selectricalsystemmeets
allapplicablerequirements,theelectricianshouldalso
consultthelocalbuildingdepartment.
Use only approved wet niches (see following note) to
ensure a safe and proper installation.
 JandyProSerieslightsareETLlisted(ETLreport/
file3141154CHI)forinstallationwithonlythefollowing
manufacturer’swetnichefixtures:
 
JandyProSeries:PLNICLRG,PLNICVFLRG,
SSNICLRG1R,SSNICLRG1S
Pentair:620004,78210200thru700,
78210401,79206700
HaywardDuraNiche:SP0600U
Sta-Rite:05161-2352thru2369,05163-2395
thru2396


JandyProSeries:PLNICSM,SSNICSM,
Pentair:78241100,78242200,78242300
78243100thru300,78244100thru300,
79206600
HaywardDuraNiche:SP0601U
Sta-Rite:05166-1017thru1034,05167-1035
thru1037
Pentair
®
and Sta-Rite
®
are registered trademarks of Pentair, Inc.
Hayward
®
is a registered trademark and DuraNiche
™
is a trademark of
Hayward Pool Products, Inc.
4" min.
48"
min.
8" min. Junction Box or Low
Voltage Transformer, to the
max water level of the pool.
18" min. to top of Lens.
11.50"
Concrete must be cut
back around Niche to
allow for a compacted
plaster seal.
Coil 4 ft. of light cable
around Fixture.
#8 AWG Ground
Connector bonding
is located at rear
of niche.
Rigid
Conduit
To GFCI, Circuit
Breaker and
Power Source.
16”
 

