Pro Series, WaterColors LED Lights
|
Installation Manual
Alignarrowofthe
lenswiththepilot
screw
Alignpilotscrewwith
thearrowlocatedon
thexturelabel
 


7. Reinstall the Jandy Pro Series Light into niche
xture.
a. Coil the extra four (4) feet of cord around the
xture or into the base of the niche and place the
light assembly into the niche.
b. Engage the retainer tab on the bottom of the face
ring, then pivot the top of the xture inward and
tighten the special pilot screw.

Useonlythespecialpilotscrewprovidedwiththis
underwaterlight.Thisscrewmountsandelectrically
groundsthehousingsecurelytothemountingring
andwetniche.Failuretousethescrewprovidedcould
createanelectricalhazard,whichcouldresultindeath
orseriousinjurytopoolorspausers,installersor
othersduetoelectricalshock.
8. If pool is empty, ll the pool until the underwater
light is completely submerged in water before
operating the light for more than 10 seconds. Turn
on main switch or circuit breaker, as well as the
switch, which specically operates the underwater
light, to check for proper operation.

Neveroperatethisunderwaterlightformorethan
10secondsunlessitistotallysubmergedinwater.
Withouttotalsubmersion,thelightassemblywillget
extremelyhot,whichmayresultinseriousburnsorin
damagetothelight.Thismayresultinseriousinjury
topoolorspausers,installers,orbystandersorin
damagetoproperty.
Thickmolded
sideofthe
gasketmust
matewith
thebodyof
thehousing
 

 

A separate 12-Volt AC Transformer is required on all 12-
Volt Models. For Jandy Pro Series WaterColors Light
use a 150-watt multi-tap 12-volt system per light.
 ForoptimumperformanceJandyProSeries
recommendstouseonetransformerper12-voltlight.
To ensure maximum safety, it is strongly recommended
that a transformer that has been listed or recognized by
a Nationally Recognized Testing Laboratory (NRTL) for
the application be used.
