Janfire NH - Technical Data

Janfire NH Burner Service Installation Manual 4.16.09 - Technical specifications are subject to change without prior
notice.
5(38)
2 Technical Data
Janfire NH Pellet Burner
Burner output capacity 10,000 – 78,000 Btu/hr (3 – 23 kW)
Maintenance output 2,000 Btu/hr (600 W)
Burner power consumption 80 W, 120 V AC, 60 Hz
Automatic ignition coil 1100 W
Pellet storage volume Internal storage: .75 gal (4 lbs) (3 litre = 1,8 kg)
Internal dosage motor 120 VAC, 60Hz
Combustion fan Variable speed operation
Self-cleaning burning chamber 120 VAC, 60Hz
Control panel Touch-button
Fuses - 10 Amp circuit breaker (reset table)
- 15 Amp fast blow fuse
External auger 1-phase 120 V AC, 60 Hz, 250 W, 4 A,
External auger cannot exceed 14 ft (4.30 m).
Weight 55 lbs (25 kg)
Figure 1. Dimensional drawing NH-burner (All measurements in mm)
