4. Mounting
4. 1 Installation location
The device is suitable for installation in
stationary and weatherproof switchboards
indoors.
4. 2 Mounting orientation
The switchboard cut-out dimension is
252mm +1mmx 174.5mm +1mm
(9.92in + 0.04in x 6.87in + 0.04in) with a
wall thickness of at most 3mm (0.12in).
252 +1
174.5 +1
R3
Fig. 03: Cutout dimensions JPC 100-PRO
For sufficient ventilation, observe the mini-
mum distance of 20mm (0.79in) around the
circumference to adjacent assemblies (to all
sides and the back).
DANGER
Danger of electric shock!
Electric shocks lead to serious injuries,
including death.
• Disconnect your system from the
power supply before mounting and
connecting the device!
• Secure it against being switched on!
• Check to be sure it is de-energized!
• Ground and short circuit!
• Cover or block off adjacent live parts!
• The installation must only be carried
out by qualified personnel with electri-
cal training!
ATTENTION
Material damage due to disregard of the
mounting instructions.
Disregard of the installation instructions can
damage or destroy your device.
• Observe the following description for
mounting and in particular the maxi-
mum tightening torque for the retaining
brackets of the device (see technical
data).
• Provide adequate air circulation in your
installation environment and cooling,
as needed, when the ambient tempera-
tures are high. Follow the general ESD
protective measures.
