8. Technical data
General
Net weight Approx. 1.25kg (2.76lb)
Dimensions 264.5mm x 187mm x 32.1mm
(10.41in x 7.36in x 1.26in)
Installation depth 26.6mm (1.05in)
Backlight (LED) Brightness: typ. 430cd/m
2
(39.95cd/ft
2
)
Chip Arm
®
i.MX8M Mini 4 Cores, 4x 1.6GHz
Main memory 1GB DDR4 RAM
Memory capacity • 4GB eMMC flash
• 2MB serial NOR flash
Cutout dimensions 252mm + 1mm x 174.5mm + 1mm
(9.92in + 0.04in x 6.87in + 0.04in)
Tightening torque for the retaining brackets 0.2Nm (1.77 in·lb)
Installation in wall thickness Max. 3mm (0.12in)
Interfaces
USB USB 2.0 type A
Ethernet • 1x RJ45
• Transmission rate 10/100/1000Mbit/s
SD card Available
Display
Type TFT (16.7 million colors)
Diagonal 10.1”
Resolution 1280 x 800 pixels
Display size 217mm x 135.6mm (8.54in x 5.34in)
Touchscreen Capacitive multi-touch
Electrical properties
Supply voltage 24V DC (via 3-pin Phoenix connector)
Current draw 150mA to 550mA
Power consumption 3.6W to approx. 14W
Fuse 2A non-renewable fuse (internal)
Overvoltage category Primary side overvoltage category II max. 300V
Environmental conditions
Protection level to EN 60529 IP65 on the front, IP20 on the back
Operating temperature 0°C to 55°C (32°F to 131°F)
Storage and transport temperature -20°C to 70°C (-4°F to 158°F)
Air humidity 10% to 90% non-condensing
Operating elevation 0 .. 2000m above sea level
Pollution degree according to IEC 61010-1 2
