Janome 1200D - Removing Back Cover

1b
REMOVING BACK COVER
3. Remove Thread guide Pole from Spool pin base.
4. Remove screw caps and screws "b" and "c" from Back Cover.
5. Remove Back Cover Unit "3" and Spool Stand "2".
6. Remove Side Cover.
Note: To remove screw caps, use a wire pin No.11007.
b
3
2
c
(14mm)
(10mm)
No.11007
+
+
12
