Janome 419S - Bobbin Case and Spool Pin Handling

7
Removing or Inserting the Bobbin Case
Open the hook cover.
Raise the needle by turning the handwheel toward you.
Take out the bobbin case by holding the latch.
When inserting the bobbin case, place the horn into the recess
of the hook race.
Hook cover
Latch
Horn
1
2
3
3
2
1
Setting Spool Pins
The spool pins are used for holding the spool of thread in order
to feed thread to the machine.
To use, pull up the spool pin. Push down for storage.
1
2
3
Needle thread
Hole
Tangle
Note : When using thread which has tendency to tangle
around spool pin, thread through the hole of spool
pin as shown.
The hole should face the thread spool.
1
1
2
3
