Specifications

Desktop Robot JR3000

11. I/O-S (Optional)

11.1 Connector

JR3200 Series

I/O-S (optional)

JR3400 Series

JR3300 Series

I/O-S (optional)

Example: JR3203N-AC/BC

Example: JR3303N-AC/BC

Example: JR3403N-AC/BC
