Janome Memory Craft 550E - Ready to Sew Window; Function Keys; Pattern Information

29
Pattern information
The visual touch screen displays the following details:
q
Hoop size
w
Dimension of the design
e
Maximum sewing speed
r
Tension setting
t
Number of thread colors (layers)
y
Required sewing time
u
Preview window
i
Cross mark (current sewing point)
o
Progress bar
!0
Stitch count
!1
Thread color
Ready to Sew Window
The Ready to Sew window shows embroidery function
keys and information on the selected pattern.
Press the down arrow key t or up arrow key y to show
the next set of function keys (u to o).
Function keys
q Color section key
w Trace key
e Thread color/Jog key
r Fine position/angle adjustment key
t Down arrow key
y Up arrow key
u Color list key
i Adjust key
o Hoop back key
!0 Stitch forward key
!1 Stitch back key
!2 Jump key
!3 Jog keys
q
w
e
r
i
o
y
t
u
!0
!1
!2
!3
q
w
e
r
t
y
o
i
!0
!1
u
