FM-200® FILL MANUAL
Revision B
Document # DOC180
Issued: August 16, 2010
Revised: April 2, 2012
2.2 Dip Tube
A rigid dip tube is threaded into the cylinder valve and extends down the entire length of the cylinder.
2.3 Cylinder Valve
A dierential pressure operated cylinder valve controls the release of FM-200® from the cylinder. It is made
of forged brass and is threaded onto the cylinder neck. e features and design of each valve vary according
to the Series designation.
Section 2 Cylinder Assembly
