Page: 9
FM-200® FILL MANUAL
Revision B
Document # DOC180
Issued: August 16, 2010
Revised: April 2, 2012
Section 3 Fill Components
3 FILL COMPONENTS
e following components are necessary to ll a Janus Fire Systems® cylinder assembly with FM-200®.
3.1 Fill Adapter
A ll adapter is installed into the discharge outlet of the cylinder valve during the ll procedure to
accommodate the attachment of the cylinder ll assembly. Each Series valve requires a dierent type of ll
adapter.
3.1.1 Sv Series Fill Adapter
P/N 99515 (See Figure 3.1.1)
e Sv Series ll adapter consists of a 1-1/4 in (32 mm) MNPT
pipe plug tted with a 1/4 in (8 mm) male quick-connect tting.
e 1-1/4 in (32 mm) MNPT connection attaches to the Sv Series
discharge valve in place of the anti-safety recoil device. e 1/4 in (8
mm) male quick-connect tting attaches to a 1/4 in (8 mm) female
quick-connect tting on the cylinder ll assembly. e male quick-
connect tting contains an internal check valve that prevents agent
from owing through the tting unless it is connected to the cylinder
ll assembly.
3.1.2 Mv Series Fill Adapter
P/N 99514 (See Figure 3.1.2)
e Mv Series ll adapter consists of a 2 in (50 mm) grooved pipe
plug tted with a 1/4 in (8 mm) male quick-connect tting. Pipe
plug attaches to the Mv Series discharge valve using the 2 in (50
mm) grooved coupling shipped with the cylinder assembly as part of
the anti-safety recoil device. e 1/4 in (8 mm) male quick-connect
tting attaches to a 1/4 in (8 mm) female quick-connect tting on
the cylinder ll assembly. e male quick-connect tting contains an
internal check valve that prevents agent from owing through the
tting unless it is connected to the cylinder ll assembly.
3.1.3 Lv Series Fill Adapter
P/N 99513 (See Figure 3.1.3)
e Lv Series ll adapter consists of a 3 in (80 mm) grooved pipe
plug tted with a 1/4 in (8 mm) male quick-connect tting. Pipe
plug attaches to the Lv Series discharge valve using the 3 in (80
mm) grooved coupling shipped with the cylinder assembly as part of
the anti-safety recoil device. e 1/4 in (8 mm) male quick-connect
tting attaches to a 1/4 in (8 mm) female quick-connect tting on
the cylinder ll assembly. e male quick-connect tting contains an
internal check valve that prevents agent from owing through the
tting unless it is connected to the cylinder ll assembly.
Figure 3.1.1 Sv Series Fill Adapter
Figure 3.1.2 Mv Series Fill Adapter
Figure 3.1.3 Lv Series Fill Adapter
1/4" (8 mm)
Male Quick-Connect
1/4" (8 mm)
Male Quick-Connect
1/4" (8 mm)
Male Quick-Connect
