Operating instructions DPK 6207…
© BA_DPK_EN_Rev06-2010.docx Page 3 of 18
Figure 1: Drawing of electric-motor driven version with cam disc
10
Housing
80
Cam disc
20
Valve handle
110
Weight
30
Sealing disc
140
Roller
40
Thrust piece
270
Limit switch
60
Packing ring
500
Drive unit (gear motor)
70
Gasket ring
