Operating instructions DPK 6207…
© BA_DPK_EN_Rev06-2010.docx Page 8 of 18
4.2 Commissioning
This work may only be carried out by trained personnel!
Work on the electrics must be carried out by a trained electrician!
Caution! Danger of injury!
Make sure that the system is switched off and secured against inadvertent activation.
Inform the control room.
Attention! Material damage!
Foreign objects and non-specification use should be avoided in the commissioning phase in
particular!
Connect electrical and pneumatic drive and monitoring components properly.
Observe the specifications given on the type indication plate and technical documentation.
Caution: Electrical drives must always be connected with overload protection.
Note the hazards from inadvertent operation following a power failure or a failure of the
compressed air supply!
(Example: valve with solenoid valve function closes so that it is de-energised)
Commissioning may only take place once it has been ensured the specifications of the Machine
Directive 2006/42/EC8/37/EC and other applicable safety instructions have been met!
See also the installation declaration.
Check the JAUDT double shuttle valve for the following in the installed state:
- Leaks (visual inspection of valve “CLOSED” position through inspection cover);
- Whether the fastening elements have been tightened securely;
- Firm seat of cam disc, operating lever with roller and overhauling weight
(for motor drive)
- Firm seat of overhauling weight (for weight-actuated drive)
- Firm seat of cylinder and valves (for pneumatic drive)
