Operating instructions DPK 6207…
© BA_DPK_EN_Rev06-2010.docx Page 4 of 18
1.1 Validity of this operating manual
This operating manual applies to the JAUDT double shuttle valves with nominal widths of between 200x200
and 600x600 with electric motor-, pneumatic- and weight-actuated drive.
Other sizes available on request.
1.2 Identification point
The identification plate in Figure 3 is fixed to each JAUDT double shuttle valve and identifies the valve. The
model number does not specify the paintwork or accessories.
Figure 2: Identification plate
When making enquiries or placing orders for spare parts, please always quote the order and model
numbers.
1.3 Other relevant documents
The confirmation of order is a part of this operating manual. It contains the following information:
- Model, identical with the model on the identification plate.
- Problem definition; the version of DPK is designed precisely for this problem definition.
- Technical specifications of the DPK and technical specifications of the drive.
Every operating manual is also accompanied by the following documents:
- Dimension sheet, spare parts list and spare parts drawing
- Operating manual with table of lubricants for motors, if supplied with a motor
- The manufacturer’s installation sheet is enclosed for JAUDT double shuttle valves with inductive limit
switches.
- The installation sheet for the 5/2-way valve is enclosed for JAUDT double shuttle valves with
electropneumatic drive.
- Special instructions for JAUDT DPK ATEX double shuttle valves if used as a device under Directive
94/8/EC or if used in potentially explosive atmospheres.
These accompanying documents are part of this operating manual!
1.4 Technical requirements for operation
Fit the drive of the powered JAUDT double shuttle valves with an appropriate safety protective device to
avoid injuries (unless already included in the scope of delivery).
Connect supply voltages:
Refer to the other relevant documents (see chapter 1.2) for the voltage specifications.
Connect compressed air supply:
Electropneumatic drive: 0.7 – 0.8 MPa (7 - 8 bar absolute, corresponds to 6 to 7 bar excess pressure),
filtered, free from water and oiled.
