57
Slideout SyStemS
Electric Slide Room System(If So Equipped)
The slideout room system is designed for additional oor space and comfort. The mechanical
components are gear driven. Electric powered slideout room systems have a manual override
to allow you to extend or retract the slideout room(s) in case of a power loss. Make sure you
have sufcient power available before operating your slideout system.
Make sure the interior slideout room path and the slideout room itself is clear
of people and objects before operating. Keep away from the slide rails and
gear assembly when the room is in motion. They may pinch or catch on loose
clothing causing personal injury. Failure to follow these instructions could
result in serious injury or death.
Make sure the vehicle is level before operating the slideout room. Water leaks
and other problems could result if the slideout is operated without leveling the
vehicle.
Make sure the slideout is in the closed position prior to hooking the unit to
the tow vehicle.
Do not place excessive weight in the slideout room. It can cause the slideout
room to malfunction and cause damage to the slideout.
Operating The Slideout
The Schwintek in-wall slideout system is designed to give you, the recreation vehicle
enthusiast, a lifetime of trouble free serecreation vehicleice. It requires no maintenance it
will never require any adjustments.
The Schwintek in-wall system has two vertical columns, a left hand and a right hand. Each
of these columns has two serpentine gear racks that are attached to the slide room. Each
side has a drive motor located at the top of the column. The right hand and left hand motors
remain synchronized by the Dual Motor SynchronousVelocity Slide Controller (a circuit
board typically located in the basement area of the recreation vehicle.
