DC FUSE PANEL LAYOUT

NOTE: Below is a typical wiring layout. Your individual trailer may be different.

1 Open --

2 Bathroom Lights & Vent 15

3 Pump/Monitor Panel/Range Hood/Sink Light 15

4 Refrigerator/Furnace 15

5 Bedroom 15

6 TV/Radio/LP Detector 15

7 Ceiling Lights 15

8 Bunk Lights 15

9 Slideout Lights 15

10 Open --

11 Open --

12 Slideout Motor 20 auto

Brakes

The electric brakes operate on 12 volt DC power from tow vehicle through blue and white

wires on the seven (7) way pigtail and harness. More information on the brakes is found in

this manual and in manufacturer supplied information.
