PLUMBING SYSTEM
PowerFill
TANK
City inlet to
tank
Dry
Camping
Water from
tank via pump
Sanitize
Siphon to
tank via pump
Winterize
Siphon to
fixtures via
pump
City Water
City inlet to fixtures
Nautilus P4 - 3 Handle www.bandbmolders.com/index.php/p4-3-handle/
Tank Fill
Pump/City
Water
Heater
Bypass
Winterize
Highland Ridge Fifth Wheel Utility Center
Suction
Inlet*
Suction Valve
*Turning on the water pump not only draws water from the fresh water tank for use in the RV fixtures, but it also enables pumping into the water
system via a hose attached to the suction inlet. This can be used for pulling in fresh water from a container using the “Tank Fill” settings (for when
pressurized water is not available to fill from the fresh water connection), pulling RV antifreeze in the plumbing lines using the “Winterize” setting,
or for pulling an anti-bacterial solution into the system for line and tank cleanings us the “Tank Fill” setting.
Tank Fill
City Fill
The lever controls whether the pressurized water entering the
fresh water connection inlet provides water directly to the fixtures
in the RV (City Fill), or simply fills the water tank (Tank Fill).
www.bandbmolders.com/index.php/product/docking-station-city-fill-tank-fill-tank-flush-no-coax-key-lock/
Starcraft / Highland Ridge Basic Utility Center
