Special function, optional parts
introduction and application
1. External Fuse (optional)
Protect the overload of the opener.
2. Burglar alarm (optional)
Track in real time the close condition of the door. If the door is pried under the abnormal situation, it will alarm loudly.
3. Photo beam/switch control connection (Fig.11, Fig.12)
4. Flash light (optional)
There are corresponding interfaces for this function and provide 24v-35v flash light
voltage. Connect the flash light with DC 24v-28v, current≤100mA. When use AC 220V
power flash lights, please match an adapter, and wiring as required(Fig.13).
5. Pass door (SD) protection (optional)
This function ensures that the door can’t be opened unless the small pass door is closed.
The door panel won’t be damaged. Connect according to Fig.14 .
Fig. 11
Fig. 12
