JBL 1500 - Electrical Parts Lists; Driver PCB Components; Preamp PCB Components

1500 Array 120V Electrical parts lis
t
Part numbe
r
Qt
y
Description Reference Designato
r
DRIVER PCB
Resistors
024-000098-120ZS 4 GS SMD Resistor 0R 1/8W J 0805 R313,314,318,320
024-100298-120ZS 4 GS SMD Resistor 10R 1/8W J 0805 R89,90,140,150
024-100498-120ZS 10 GS SMD Resistor 1K 1/8W J 0805 R81,85,96,97,131,137,142,147,162,179
024-100598-120ZS 12 GS SMD Resistor 10K 1/8W J 0805 R75,83,92,98,132,133,151,156,163,164,183,82,
024-110598-120ZS 2 GS SMD Resistor 11K 1/8W J 0805 R74,99
024-200598-120ZS 4 GS SMD Resistor 20K 1/8W J 0805 R95,141,148,181
024-220398-120ZS 2 GS SMD Resistor 220R 1/8W J 0805 R136,167
024-220498-121ZS 1 GS SMD Resistor 2K2 1/8W J 0805 R134
024-220598-120ZS 1 GS SMD Resistor 22K 1/8W J 0805 R37
024-220798-120ZS 2 GS SMD Resistor 2M2 1/8W J 0805 R87,93
024-270498-120ZS 3 GS SMD Resistor 2K7 1/8W J 0805 R80,84,157
024-390498-120ZS 2 GS SMD Resistor 3K9 1/8W J 0805 R130,161,
024-390598-120ZS 2 GS SMD Resistor 39K 1/8W J 0805 R86,94
024-470398-120ZS 1 GS SMD Resistor 470R 1/8W J 0805 R91
024-470498-120ZS 4 GS SMD Resistor 4K7 1/8W J 0805 R34,36,152,153
024-470598-120ZS 1 GS SMD Resistor 47K 1/8W J 0805 R35
024-470698-120ZS 2 GS SMD Resistor 470K 1/8W J 0805 R32,33
024-560598-120ZS 1 GS SMD Resistor 56K 1/8W J 0805 R38
024-680498-120ZS 2 GS SMD REsistor 6K8 1/8W J 0805 R135,166
Capacitors
031-100244-100ZS 4 GS SMD Ceramic cap. 0u01/50V K 0805 X7R C108,118,131,140
031-100343-100ZS 2 GS SMD Cap. 100pF/50V J 0805 NPO C81,84
031-100344-100ZS 6 GS SMD Cap. 0u1/50V K 0805 X7R C75-78,82,85
031-180344-100ZS 2 GS SMD Cap. 0u18/50V K 0805 X7R C80,83
031-470244-102ZS 4 GS SMD Cap. 0u047/50V K 0805 X7R C93,94,101,124
031-560243-100ZS 4 GS SMD Cap. 56pF/50V J 0805 NPO C92,102,105,125
031-560343-102ZS 1 GS SMD Cap. 560pF/50V J 0805 NPO C79
034-100614-300ZS 1 GS Elec. Cap. 100uF/16V M (R)0611 P:2.5 C117
Semiconductors
054-000100-100ZS 2 GS SMD DIODE: PN:ES1D 200V 1A D35,43
054-005501-100ZR 1 GR SMD ZENER DIODE PN:BZV55C3V6 (PHILIPS) D60
054-007200-100LZS 2 GS SMD IC: (JRC) M072M-DUAL OP-AMP U9,10
054-008406-000ZR 2 GR SMD ZEN DIODE:(PHILIPS) BZX84C10-7-F SOT-23 D42,49
054-008408-000ZR 2 GR SMD ZEN DIODE:(PHILIPS) BZX84C5V6-7-F SOT-23 Z7,8
054-033906-100ZR 2 GR SMD Transistor (ON) PN:MMBT3906LT1G SOT23 Q34,35
054-414803-100ZS 5 GS SMD DIODE: PN:LL4148 MINI-MELF D36,39,46,52,61
054-540100-100ZR 2
GR SMD Transistor PNP (ON SEN) MMBT5401 LT1 SOT-23
Q33,40
054-555100-100ZR 1 GR SMD Transistor (NPN) PN:MMBT5551 LT1R (ON) Q32
051-222200-100ZR 2
GR Transistor NPN (ON SEM) PN:MPS2222ARLRAR TO-92
Q20,22
051-555100-000ZR 2 GR Transistor NPN PN:2N5551 TO-92 Q21,23
051-000600-100ZR 1 GR Transistor NPN PN:MPSW06RLRA TO-92 (ON) Q31
053-211100-000ZR 2 GR IC:DIP,HALF-BRIDGE DRIVER PN:IR2111 8PIN (IR) U7,8
Miscellaneous
072-040229-000ZR 1 GR HEADER Right Angle PN:211-107-000-400 7PIN PIN2
072-040230-000ZR 1 GR HEADER Right Angle PN:211-111-000-400 11PIN PIN1
PREAMP PC
B
Resistors
024-000097-120ZS 5 GS SMD Resistor PN:1206J000 0R 1/4W J 1206 R258,290,297,302,303,
024-100497-100ZS 4 GS SMD Resistor PN:1206F102 1K 1/4W F 1206 R238,264,288,291
024-100598-121ZS 15 GS SMD Resistor 10K 1/4W J 1206 R202,206,207,212,222,235,252-254,257,228,229,262,268,284
024-150498-121ZS 1 GS SMD Resistor 1K5 1/4W J 1206 R251
024-150598-100ZS 1 GS SMD Resistor 15K 1/8W F 0805 R223,
024-200597-100ZS 5 GS SMD Resistor PN:1206F203 20K 1/4W F 1206 R256,208,209,231,232
024-220298-121ZS 1 GS SMD Resistor 22R 1/4W J 1206 R249
11
1500 Array Subwoofer
