VA7 SPECIFICATIONS
Rated Power Output 125W per channel into 8 ohms, all channels driven
THD <0.01%, 20Hz –20kHz
Input Impedance 20k ohms
Sensitivity 1V in = 100 watts out
Frequency Response (at 1W) 20Hz – 20kHz, +0, –0.25dB
S/N Ratio (A-weighted at rated power ) ≥100dB
Damping Factor (8 ohms) ≥380
Power Bandwidth 1% THD 10Hz – 100kHz, +0, –3dB
Intermodulation Distortion ≤0.03%
Dimensions (H x W x D) 5-1/2" x 17-5/16" x 16-1/4" (140mm x 440mm x 413mm)
Net Weight 55.5 Ib (25.19kg)
Packaged Weight 65.5 Ib (29.73kg)
A
ll features and specifications are subject to change without notice.
