JBL Cinema Sound CSS10 - EXPLODED VIEW

Item# Part Number Description Qty
1 249-ABS-05080-0VAE Port Tube (Outer Portion) 1
2 249-ABS-05095-0VAE Port Tube (Inner portion) 1
3 Not Available CSS10 Cabinet 1
4 Not Available Dacron Filler 1
5 Not Available CSS10 Amplifier 1
6 352-AM04020D210-E Amplifier Screws 10
7 316-CU-05174-0VAE JBL Logo 1
8 25PR12FZL-DW01 10” (250mm) Woofer DCR = 3.5Ω 1
9 352-FM04020D605-E Woofer Screw 8
10 321-ABS-00008-0BAE Plastic foot 4
11 352-HM04030D500-E Foot Screws 4
12 321-RUB-00009-0BAE Foot Pads 4
9
CSS10 Cinema Sound
