JBL Cinema Sound CSS10 User Manual

CSS10 150W Powered Sub/ Plate Amp
LINE VOLTAGE Yes/No Hi/Lo Line Unit Notes
US 120vac/60Hz Yes 108-132 Vrms
Normal Operation
EU 230vac/50-60Hz Yes 207-264 Vrms Normal operation, MOMS required
Paramete
r
Specification Unit QA Test Limit
s
Conditions Notes
Amp Section
Type (Class AB, D, other) D D
n/a
Load Impedance (speaker) 4 Ohms
n/a Nominal
Rated Output Power 150 Watts
145 1 input driven
THD@ Rated Power 0.08 %
1 22K filter
THD @ 1 Watt 0.1 %
0.5 22K filter
DC Offset 10 mV-DC
20 @ Speaker Output
Damping factor >100 N/A
15 50Hz-4 Ohms load
Measured at amplifier PCB speaker out
connector @ power 135 Watts.
Input Sensitivity
Input Frequency 50 Hz
50 Nominal Freq. 1 input driven
Line Input (L&R) 12 mVrms
±2dB To 1 Watt 1 input driven
LFE Input 7.63 mVrms
±2dB To 1 Watt LFE input driven only
Signal to Noise
SNR-A-Weighted 100 dBA
85 rel. to rated power A-Weighting filter
SNR-unweighted 90 dBr
80 rel. to rated power 22K filter
SNR @ 1W-unweighted 60 dBr
55 rel. to 1W Output 22K filter
Residual Noise Floor 1 mVrms
2
Volume @max, using RMS reading
DMM/VOM (or A/P)
Residual Noise Floor 1
mVrms(max)
2
Volume @max, w/ A/P Swept Bandpass
Measurement (Line freq.+ harmonics)
Input Impedance
Line input L&R , LFE >15 K ohms
n/a Nominal
Filters
Left & Right Low Pass fixed Hz --
±2dB
Slope & Q 4th dB/Octave
n/a
LFE Low Pass fixed Hz --
±2dB
Slope & Q 2nd dB/Octave
n/a
Subsonic filter (HPF) Hz --
±2dB
Slope & Q 2nd dB/Octave
n/a
Limite
r
(yes/no) YES --
n/a
Features
LFE Input YES
functional BW Limited to 500 Hz
Phase Switch (yes/no) YES --
functional
Volume pot Taper (lin/log) LOG --
functional
ATO (Auto-ON) YES
functional
Input Configuration
Line In (L,R) L ,R --
functional RCA inputs: L , R
Line level in LFE LFE
functional
Signal Sensing (ATO)
ATO test Frequency 50 Hz
ATO Line Level 2 mV
functional
2mV@50Hz into Line Input w/ 1 ch.
driven
ATO Turn-on time 5 ms
functional
Amp connected and AC on, then input
signal applied
Auto Mute/ Turn-OFF Time 15 minutes
functional T before muting, after signal is removed
A
uto turn off time
(
T
)
must be
5min > T <15min
Power on Delay time 3 sec.
functional AC Power Applied
Transients/Pops
ATO Transient 5 mV-peak
10 @ Speaker Outputs
Turn-on Transient 50 mV-peak
100 @ Speaker Outputs AC Line cycled from OFF to ON
Turn-off Transient 50 mV-peak
100 @ Speaker Outputs AC Line cycled from ON to OFF
Efficiency
Stand-by Input Power 14 Watts
16 @ nom. line voltage
Maximum allowable input power under
nominal Input voltage and frequency, HOT
or COLD operation.
3
CSS10 Cinema Sound
