JBL Cinema Sound CSS10 User Manual

- CONTENTS -
BASIC SPECIFICATIONS…………………………………………..1
PACKAGING…………………………..……………………………2
DETAILED SPECIFICATIONS…………………………………….3
CONNECTIONS..………………………………………………….. 5
OPERATION ………….…………………………..….….………….6
BASIC TROUBLESHOOTING…………………………………….7
TEST SETUP AND PROCEDURE…………………………….…8
EXPLODED VIEW……………………………………………….…9
120V BLOCK DIAGRAM..……………………………………..….10
120V ELECTRICAL PARTS LIST …………….…….…………..11
PCB DRAWINGS………………..………………………………...15
INTEGRATED CIRCUIT/TRANSISTOR PINOUTS………....20
120V SCHEMATICS.……….………………………..…. ………21
CSS10 BASIC SPECIFICATIONS
Amplifier Power 150 Watts RMS
Frequency Response 27Hz – Low-pass crossover setting at signal source
Low-Frequency Driver 10" (254mm) cone, video-shielded
Input LFE and preamp level
Dimensions (H x W x D) (including feet) 18-1/4" x 13-1/4" x 16" (464mm x 337mm x 406mm)
Weight 43 lb (19.5kg)
Occasional refinements may be made to existing products without notice but will always meet or exceed original
specifications unless otherwise stated
1
CSS10 Cinema Sound

JBL Cinema Sound CSS10 Specifications

General

Brand	JBL
Model	Cinema Sound CSS10
Category	Amplifier
Language	English
