JBL CSA-2120 Operation Manual

5
EC - DECLARATION OF CONFORMITY
Brand: JBL
Equipment Type: Amplifier and Transformer
Model names: CSA-2120, CST-2120
We, Harman International, declare under our sole responsibility that the product, to which this declaration relates, is in
conformity with the following standards.
Due to line current harmonics, we recommend that you contact your supply authority before connection.
We certify that the product identified above conforms to the requirements of the EMC Council Directive 89/336/EEC as amended
by 92/31/EEC, and the Low Voltage Directive 73/23/EES as amended by 93/68/EEC.
Report No. Description
EN 55103-1:1997 EMC Compatibility – Product Family Standard for Audio, Video, Audio-Visual and
Entertainment Lighting Control Apparatus for Professional Use, Part 1: Emissions
EN 55103-1:1997 Magnetic Field Emissions – Annex A @ 10cm and 20cm
EN 61000-3-2:2005
& AMD1:2008
Limits for Harmonic Current Emissions (equipment input current less than or equal to 16A
EN 61000-3-3:2008 Limitation of Voltage Fluctuations and Flicker in Low-Voltage Supply systems Rated Current
less than or equal to 16A
EN 55022:2010 Limits and Methods of Measurement of Radio Disturbance Characteristics of ITE: Radiated
& Conducted, Class B Limits
EN 55103-2:1997 EMC Compatibility – Product Family Standard for Audio, Video, Audio-Visual and
Entertainment Lighting Control Apparatus for Professional Use, Part 2: Immunity
EN 61000-4-2:2001 Electrostatic Discharge Immunity (Environment E2-Criteria B, 4k V Contact, 8k V Air
Discharge)
EN 61000-4-3:2006 Radiated, Radio-Frequency, EMC Immunity (Environment E2, Criteria A)
EN 61000-4-4:2007 Electrical Fast Transient/Burst Immunity (Criteria B)
EN 61000-4-5:2006 Surge Immunity (Criteria B)
EN 61000-4-6:2006 Immunity to Conducted Disturbances Induced by Radio-Frequency Fields (Criteria A)
EN 61000-4-11:2001 Voltage Dips, Short Interruptions and Voltage Variation
Safety Standard:
IEC 60065:2001 – 7th Ed.
& AMD1:2005
Safety Requirements – Audio, Video, and Similar Electronic Apparatus
European Representative’s
Name and Address:
David Budge
10 Harvest Close
Yateley, GU46 6YS
United Kingdom
Responsible for the technical
documentation is:
Wilson Zhou
Wilson.Zhou@harman.com

JBL CSA-2120 Specifications

General

Output Power (two channels at 1 kHz power, THD+N<0.5%):	4 Ohms 120 W 8 Ohms 120 W
Frequency Response (1 watt into 4 or 8 Ohms):	+1/-1 dB
Load Impedance:	Rated for 4 or 8 Ohms
Sensitivity (8 Ohms load):	1.4 Vrms
Signal to Noise Ratio (below rated 8-Ohm power at 1 kHz, A weighted):	>100 dB
Crosstalk (Rated into 8 Ohms):	70 dB below rated from 20 Hz to 1 kHz; 50 dB below rated at 20 kHz
Input Impedance (nominal):	Balanced: 20 k Ohms Unbalanced: 10 k Ohms
Maximum Input Signal:	+20 dBu typical
AC Line Voltage and Frequency Confgi urations Available:	100-240 V, 50/60 Hz
Auto-Standby:	Go into auto-standby: 1 hour Recovery time: < 1 ms Recovery threshold: -60dBu
Operating Temperature:	0° C to 40° C at 95% relative humidity (non-condensing)

Weight and Dimensions

Dimensions (W x H x D) :	8.2” x 1.7 x 7” (209 mm x 44 mm x 178 mm)
Net Weight:	1 kg (2.1 lbs)
Shipping Weight:	1.5 kg (3.4 lbs)
