Figure 2.2.1 Dimensions
CSM 14
CSM 28
Figure 2.2.2 Mounting Kit
long angle bracket
(CSM 14 only)
flat bracket
(CSM 14 only)
front angle bracket
218.44 mm [8.6 in]
303.4 mm [11.9 in]
43.3 mm
[1.7 in]
436.88 mm [17.2 in] 303.4 mm [11.9 in]
43.3 mm
[1.7 in]
