2.4 Wiring Your Audio System
Typical input and output wirings are shown in Figure 2.4.
INPUTS: Connect input wiring for both channels using either the RCA or the
Euroblock input for each channel.
OUTPUTS: The mixer’s line level output may be connected to the input of a power
amplifer such as a JBL Commercial Series Amplifer.
Figure 2.4 Wiring Audio System
