Solution C: Rack Mounting Full Rack Mixer
To install a full-rack width unit, refer to Figure 2.2.5 and follow the steps below:
1. Attach the front angle brackets to each side of the front of the unit using the
screws provided.
2. Install the unit into the cabinet using the rack mount screws through the front
angle brackets. For details of installation in the chassis of the cabinet, refer to
the user guide of your cabinet.
Figure 2.2.5 Rack Mounting A Full-rack Mixer
