3) Connect New Data Bus Cable From Loader To Main PCB, using 12 wire - FCC CABLE part# 55174860.
Figure 6 . The data bus connector of Main B’D
4) Replace molex connector and replace any cable ties that were cut.
IV) Reassemble and test the unit; replace front faceplate and top cover.
20
DVD600
