JBL E250P - Semiconductors List

Part Number Description Reference Designator Qty
024-470698-120 SMD Resistor 470K 1/8W J 0805 R70 1
024-470798-120 SMD Resistor 4M7 1/8W J 0805 R60 1
024-487498-100 SMD Resistor 4K87 1/8W F 0805 R51,53 2
024-510398-120 SMD Resistor 510R 1/8W J 0805 R57 1
024-560598-120 SMD Resistor 56K 1/8W J 0805 R122 1
024-620398-100 SMD Resistor 620R 1/8W F 0805 R16,18 2
024-680498-120 SMD Resistor 6K8 1/8W J 0805 R46,91,40,41,43,42 6
024-680598-120 SMD Resistor 68K 1/8W J 0805 R33,34,31,50,52,66 6
024-820598-120 SMD Resistor 82K 1/8W J 0805 R69 1
025-010300-000 Thermister TSE-103 K L:50mm 1
026-200595-269 Freq Pot 20K PN:RD163121R03D-20KBx2(EJ) VR2 1
026-500495-252 Level Pot 5K PN:RK163111R52B-5KA (EJ) VR1 1
Capacitors
031-100244-100 Ceramic Capacitor 0u01/50V K 0805 X7R C33,45,51,66,67,5,10 7
031-100343-100 SMD Capacitor 100pF/50V J 0805 NPO C36,58,16 3
031-100344-100 SMD Capacitor 0u1/50V K 0805 X7R C11,42-44,46-49,52,54,55,60,63,71,74,77 16
031-100384-100R SMD Capacitor 0u1/250V K 1206 X7R C3,7 2
031-220344-100 SMD Capacitor 220pF/50V J 0805 NPO C20,21,19,14,15 5
031-330444-300 SMD Capacitor 3300pF/50V K 0805 X7R C40,34 2
031-470244-102 SMD Capacitor 0u047/50V K 0805 X7R C62,59 2
031-560243-100 SMD Capacitor 56pF/50V J 0805 NPO C57,61 2
031-560343-102 SMD Capacitor 560pF/50V J 0805 NPO C56 1
032-100484-200 Mylar Capacitor 1uF/250V K P:15 C70,C70B 2
033-470444-270 NPE Capacitor 4u7/50V K10 (R)8x13 SBE C73 1
033-680464-270 NPE Capacitor 6u8/100V K10 (R)1020 GNE C72 1
034-100525-300 Electrolytic Capacitor 10uF/25V M (R)0511 P:5 C35 1
034-100625-300 Electrolytic Capacitor 100uF/25V M (R)6.3x11 P:5 C64 1
034-220525-301 Electrolytic Capacitor 22uF/25V M (R)5x11 P:5 C4,9,41,39,50,53 6
034-220615-301 Electrolytic Capacitor 220uF/16V M (R)0611 P:5 C37 1
034-330525-300 Electrolytic Capacitor 33uF/25V M (R)0511 P:5 C1 1
034-330615-300 Electrolytic Capacitor 330uF/16V M (R)0812 P:5 C12,78 2
034-330780-300 Electrolytic Capacitor 3300uF/80V M (R)22x48 C6,8 2
034-470415-301 Electrolytic Capacitor 4u7/50V M (R)0511 P:5 C2 1
034-470615-301 Electrolytic Capacitor 470uF/16V M (R)0812 P:5 C65 1
038-100363-300 MPE Capacitor 0u1/100V J C68,69,26,27,28,29,30 7
038-150393-300 MPE Capacitor 0u15/63V J C25 1
038-330393-300 MPE Capacitor 0u33/63V J C31 1
039-100384-100 Safety Capacitor PN:HQX0.1K275VACx2 18x6x12mm CXAC1 1
Semiconductors
051-000600-100 NPN Transistor PN:MPSW06RLRA TO-92 (ON) Q2,Q16 2
051-003100-000 NPN Transistor PN:TIP 31C TO-220 (MOSPEC) Q4 1
