JBL E250P - Miscellaneous Parts List

Part Number Description Reference Designator Qty
051-005600-100 PNP Transistor PN:MPSW56RLRA TO-92 (ON) Q3 1
051-222200-100 NPN Transistor PN:MPS2222ARLRA TO-92 Q21 1
051-290700-100 PNP Transistor PN:MPS2907A RLRA TO-92 Q19,23 2
051-540101-000 PNP Transistor PN:2N5401 TO-92 Q1 1
051-555100-000 NPN Transistor PN:2N5551 TO-92 Q17 1
051-640001-000 MOSFET N-Channel PN:IRF640N TO-220 (IR) Q18,22 2
052-400080-000 Bridge Regulator PN:RS804 400V,8A BR1 1
053-211100-000 IC;DIP,Driver PN:IR2111 Half-Bridge Driver U7 1
054-000100-100 SMD Diode PN:ES1D 200V 1A D5,26,29,33,38 5
054-001002-100 SMD Zener Diode PN:BZX84C10 10V SOT-23 D35 1
054-001501-100 SMD Zener Diode PN:BZX84C15 15V SOT-23 D6,7,9 3
054-007200-100 SMD IC; (Dual OP-Amp) PN:TL072CDR SO-8 (TI) U5,6 2
054-007400-100 SMD IC;(Quad OP-Amp) PN:TL074CDR (TI) U2,3 2
054-011400-100 SMD Transistor PN:DTC114TKA SMT3 Q7 1
054-033904-100 SMD Transistor PN:MMBT3904LT1 SOT23 Q11,14,13,5,8,9 6
054-033906-100 SMD Transistor PN:MMBT3906LT1 SOT23 Q6,10,12,15 4
054-045580-100 SMD IC; (Dual OP=Amp
)
PN:NJM4558M-TE3 DMP-8 U4 1
054-050601-100 SMD ZENER DIODE PN:BZX84C5V6 5.6V SOT-23 D24,36,37 3
054-414803-100 SMD DIODE PN:LL4148 (Wishay) D1-4,8,10-23,27,28, 21
054-540100-100 SMD Zener Diode PN:MMBT5401 LT1 SOT-23 Q20,24,26 3
054-555100-100 SMD Zener Diode PN:MMBT5551 LT1 Q25 1
050-505200-001 LED PN:LT-2402-21 D1B 1
Miscellaneous
065-050400-000 Sleeve φ3.5mm BLK F32 (125)
065-100200-000 UL Sleeve φ2.5 F32-2.5(blk) 125
082-022640-000 Wire Set #26 UL1007 L=400mm blk/wht 2P Housing +5TT
091-000182-000 LED Holder PN:LED5-2A
044-100100-000 SMD Ferrite Bead PN:321611 600R/100MHz 1206
041-115001-000 Bead Coil YT-10911 L5 1
042-010053-003 Transformer YT-10615-4 PT1 1
043-300101-000 Inductor 30uH YT-10033 L2 1
043-324300-000 Inductor 324uH YT-10778 L4 1
043-560200-000 Inductor 56uH YT-10779 L1 1
043-700101-000 Toroidal Inductor 70uH YT-10682 L3 1
008-001008-062 Label 97x74.8 t=0.254mm
008-002007-033 Label 200.3x71.1 t=0.254mm
008-061215-000 Gasket C4305 12x15 t=5mm CR
008-062002-002 Gasket PN:L-32 200x20mm t=5mm PORON
008-062002-012 Gasket (PB10/12) 200x20mm t=2mm CR4305
008-063208-000 Gasket C4305 321x8 t=1mm CR
008-069304-000 Gasket C4305 93x4 t=1mm CR
061-020000-000 Knob ABS φ20x15m/m UL94V-0 BLK
061-314002-000 Strain Relief P/N SB4F-2
E250P
22
