JBL E250P - Page 24

Part Number Description Reference Designator Qty
061-400014-000 Rubber Foot ID:6.2 OD:11.5 t=2mm blk
061-700044-000 Mycar 13x18mm TO-220
063-010012-000 Brckt for pwr transistor P/N:TRK-1
063-321100-001 Plate 322x105.7x15mm BLK (94V0)ABS
063-531808-000 Bucket 322x105.7x146.5mm blk (94VO)
066-120300-900 Cable Tie CV-120S
071-100608-100 Fiber Washer OD=8mm ID=3.2 t=1 (red)
071-100851-000 Washer ID=5.1 OD=12 t=1m/m
072-010007-000 RCA Jack SCJ-1020 2P(G) wht, red
072-040039-000 Terminal PC205 (t=0.8m/m) T205MA
072-040064-000 Terminal PC250(t=0.8),T250MA
072-040096-000 Terminal T187MA (t=0.8mm) PC187(0.8) AC1,AC3,T1,T2,AC2,SW2,SW4
072-040169-000 Connector 2 PIN JS-1001-2 P:2.5mm
072-060170-000 B.P. W / Accessory Parts
073-032315-601 Black Anodized 70x58x20mm
073-050001-000 Fuse Clip P/N:CFFH1206
074-020018-000 Rocker SW PN:RF1003-BB4-0
074-030002-000 Toggle SW PN:L101-T2B4QE SW5,SW6 2
074-300018-000 Relay PN:943-1C-48D K1 1
082-022241-001 Wire set #22 UL1007 L=410mm blk/wht
083-041802-009 Power Cable SPT-2 blk T187
093-105202-300 Fuse FUSE:2A,250V,5*20mm F1 1
181-911600-161 Wire #16AWG UL1007
blk L=610mm
181-911655-135 Wire #16AWG UL1007
green L=610mm
181-921600-000 blk wire #16 UL1015 T187 L:140mm
181-921699-000 wht wire #16 UL1015 T187 L:160mm
